Autofocus Camera Series

Intelligent Imaging AF Platform

Integrating five major functions of "focus, zoom, encoding, storage, and networking" into a single 4K HDMI camera, it can replace traditional microscope mechanical operations while seamlessly connecting to digital classrooms, production line quality control, and remote collaboration systems. This is the best choice for microscopic imaging entering the "plug-and-play" era.
Explore Core Features

Product Description

The Autofocus Camera Series is an intelligent imaging AF platform upgraded from the original HDMI camera series. It integrates Sony STARVIS/STARVIS 2 back-illuminated CMOS sensors, GPU-level ISP, autofocus algorithms, and multi-interface encoding/decoding modules into a palm-sized device. It can lock onto the focal plane within 0.3 seconds and simultaneously output 4K 60 fps via HDMI, USB 3.0, Gigabit LAN, and 5 GHz Wi-Fi, meeting the "plug-and-play" requirements for teaching broadcasts, industrial quality inspection, and scientific imaging recording scenarios.

Ultra-Fast Autofocus

0.3-second one-touch focus with manual fine-tuning, single-shot focus, and conjugate calibration functions to ensure fast and precise target locking every time

Motorized Continuous Zoom

18×/20× optical zoom (AFDM series) with synchronized memory of magnification and illumination for seamless magnification switching

4K Multi-Interface Output

HDMI 2.0 60 fps + USB 3.0 UVC + Gigabit LAN H.265 + 5 GHz Wi-Fi concurrent output

Embedded Software

XCamView: measurement, focus stacking, real-time stitching, WDR, voice control, and other intelligent functions

Local Storage

SD/USB H.265 4K 60 fps recording with power-off resume capability, ensuring data security

Open SDK

Supports Windows/macOS/Linux/Android/iOS multi-platform development with rich programming interfaces

Core Features

Dimension Description
Ultra-Fast Autofocus 0.3 s one-touch focus + manual fine-tuning + single-shot focus + conjugate calibration
Motorized Continuous Zoom 18× / 20× optical zoom (AFDM series), synchronized memory of magnification and illumination
4K Multi-Interface Output HDMI 2.0 60 fps + USB 3.0 UVC + Gigabit LAN H.265 + 5 GHz Wi-Fi concurrent
Embedded Software XCamView: measurement, focus stacking, real-time stitching, WDR, voice control
Local Storage SD / USB H.265 4K 60 fps recording with power-off resume support
Open SDK Windows / macOS / Linux / Android / iOS (C/C++, C#/.NET, Python, DirectShow, TWAIN)
Industrial-Grade Design -10 °C~50 °C operating temperature, all-metal heat dissipation housing, 12 V DC power supply

Series Classification and Quick Selection Guide

Choose the most suitable product series based on your specific application requirements

Recommended Series

Need Autofocus + Motorized Continuous Zoom

AFDM Series
Built-in 18× / 20× motorized zoom tube, 150–195 mm working distance
Selection Rationale: Integrated microscopy system, eliminates time for changing objectives and manual focusing, suitable for microscopic video inspection and rapid magnification switching scenarios
Flexible Integration

Existing C / EF Mount Optical System

XFCAM Series
C/EF interface body, no built-in zoom
Selection Rationale: Seamless integration with existing microscopes or industrial lenses, achieving 4K autofocus output
Plug-and-Play

Pursuing Minimal Integration, One-Touch Operation

AFDM + Supporting Light Source
AFDM ring/coaxial LED linked with magnification
Selection Rationale: Ready to use out of the box, shortest deployment path, suitable for rapid imaging system setup
Customization

Pursuing Custom Optical Path, High Magnification Combinations

XFCAM + Continuous Zoom Objective (TZM)
External 0.4–8× / 0.6–12× motorized or manual zoom tube
Selection Rationale: Flexible assembly, adapts to various working distances and magnifications, meeting special application requirements

Application Scenarios

Widely used across various industries, providing professional imaging solutions

Electronics Manufacturing

SMT solder joints, BGA, PCB copper foil defect inspection
Autofocus + motorized zoom for rapid switching between wide-area and local detail views

Materials Research

Metallographic / DIC / polarization microscopic structure observation
4K 60 fps HD HDMI direct connection to large screens for real-time demonstration and discussion

Life Sciences

Cell culture, tissue section teaching
Wi-Fi streaming to tablets for synchronized teacher-student observation; measurement and annotation directly saved

Failure Analysis

Die scratches, ceramic cracks, solder layer voids
Focus stacking + high magnification zoom for clearer three-dimensional defect visualization

Mobile Teaching / Exhibitions

Classroom demonstrations, exhibition displays
HDMI large screen + Wi-Fi handheld terminal simultaneous output, zero PC burden
